3 Ton High Rise Hydraulic Scissor Lift Car Hoist: WES-SH3

3 Ton High Rise Hydraulic Scissor Lift Car Hoist: WES-SH3

Our specialist sales support team can answer all your questions and concerns:


 Features :

  • Conform to Australian Standard, Work Safe Vic design registration no : WSV-0150533341.
  • The main structure is designed as ultra-low 100mm, which is convenient for the maintenance of ultra-low chassis vehicles.
  • Scissor arms are made of 20mm x 85mm Q345 (16Mn) Cold Drawn steel technology.  Cold drawn steel has an improved yield strength and tensile strength, has an improved surface finish than hot rolled steel.
  • The platform steel used is 6mm thick.  It is reinforced with steel stiffeners.
  • The ramp is made with double layer of 5mm checkered steel plate.
  • The dual oil line cylinder synchronizing system ensures that both platforms raise or descend in synchronize manner.
  • Each platform has 2 hydraulic cylinders (60mm and 70mm diameter) with 38mm diameter piston.  These sizes are very strong for performance in this lift.  The Italy Aston oil seal is used.  And the Taiwanese dust proof seal is used for better seal and performance of the hydraulic cylinder.  Better sealing enhances lifting performance of lift.
  • Resin high pressure hose is used to prevent bursting.
  • The new ultra-thin shear does not use the old mechanical lock.  It uses the pump station to control the double oil circuit electromagnetic hydraulic lock, a high degree of safety.  Much safer than the traditional old mechanical lock.   Double oil control is safer in the sense that if one oil pipe bursts, the other oil pipe starts safety measures to ensure the stability of the machine.  Emergency stopping is also very safe, allowing the machine to drop slowly through the pump station’s safety valve, thus ensure the overall safety of the machine.
  • Powder coated finish.

Any Questions?

Call us now 03 9308 2600 / 0478 352 352 to discuss which model suits your needs


Technical Specifications :

  • Power : 2.2kw (240V)
  • Lifting capacity : 3000kg
  • Maximum lifting height : 1830mm
  • Lift minimum stand height : 100mm
  • Platform length : 1490mm
  • Platform width : 602mm
  • Overall length : 2050mm
  • Overall width : 2032mm
  • Space between platforms : 828mm
  • Lifting time (240V) : ≤50s
  • Decending time (240V) : ≤30s
  • Noise : ≤70db
  • Operating temperature : 10°C/+45°C
  • Work environment : Closed room

* Photo is for illustration purpose only.  Actual item and/or specifications may vary due to regular product improvement. Please check before ordering.

Product Warranty: 1 year parts under normal usage and maintenance, exclude wear and tear, back to base in Craigieburn, Victoria.

Item is located at Workshop Equipment Store® – 1 Export Road, Craigieburn, Vic 3064

We encourage potential buyers to come to our shop to see product demonstrations at the same time allow us to show you how our machines are different from the others.

Please email us the Suburb and Post Code to get quote for freight.  We also need to know if there is forklift at your premises to unload.  If there is no forklift, you may have to collect from the depot nearest to your area.  Please note the freight company will only delivery to a commercial property (or a depot if no forklift available to unload at the commercial property).

Packaging :

  • 165cm (L) x 62.5cm (W) x 38cm (H), 730kg
  • 110cm (L) x 40cm (W) x 35cm (H), 70kg

Call us now 03 9308 2600 / 0478 352 352 to discuss which model suits your needs.
